• Includes an M-12 Quick Connector.
• PATLITE's exclusive hybrid prism-cut lens to enhance visibility from any direction and distance.
• Double Insulation for enhanced durability and safety in the work environment.
•Direct mount installation with just a single hole.
• Interchangeable LED modules needing no re-wiring, even after installation.
• Main Body made of heat resistant ABS resin for superior impact resistance.
• Lens made with light translucent AS resin for superior weather resistance.
• Available colors are in Red, Amber and Green.
|DIMENSIONS||- 30mm diameter|
|OPERATING VOLTAGES||- DC 24V (Non-polar)|
|FUNCTIONS||- Continuous Lighting Only
- Dry contact closure such as switches or relay contacts
- Open-collector transistor (NPN or PNP) for DC24V
- Direct voltage control
|MOUNTING||- Direct mount only: includes M22 mounting nut and sealing gasket|
|BODY STYLE||- M-12 Quick Connector (Cable sold separate)
- Pre-assembled, pre-wired
- Modules interchangeable and stackable after purchase
|BODY COLOR||- Body: Silver|
|STACKABLE TIERS||- From 1 to 3 modules can be stacked|
|MODULE COLORS||- Red
|CONFORMITY STANDARDS||- CE Marking
- UL Component Recognition (US)
- c-UL Component Recognition (Canada)
- RoHS Compliant
|PROTECTION RATINGS||- IP-65|
