• Disponibile solo per montaggio a incasso.
• Riproduce suoni fino a 95dB (a 1m) nonostante le dimensioni compatte
• Il controllo sul pannello anteriore permette di regolare il volume in tutta semplicità.
• L’uso di una scheda SD consente di cambiare i messaggi senza smontare il dispositivo.
• Rispetta l’ambiente grazie alla conformità alle direttive RoHS dell’Unione Europea.
• Disponibili varie modalità di riproduzione per diverse applicazioni.
• Ingresso binario in dotazione standard per selezionare fino a 31 messaggi.
• Supporta la selezione degli ingressi mediante transistor NPN a collettore aperto.
• L’unità è conforme alle direttive UE e dispone della marcatura CE (solo BKV-31JF)
• Disponibile in due colori per intonarsi all’impianto.
• Classe di protezione: IP54 (solo sul lato anteriore se incassato)
DIMENSIONS | - 120mm x 120mm x 62.8mm |
---|---|
RATED VOLTAGE | - DC12/24V - AC100V* *Special Order Item |
MOUNTING | - Panel Mount - Vertical mounting angle only - Indoor: Upright, upside-down, sideways - Outdoor: Upright only |
BODY COLOR | - Dark Gray - Light Gray |
VOLUME | - Maximum 95dB at 1 meter - Adjustable volume control |
SOUND STORAGE | - Approximate Recording Time: 63 seconds (Bit rate=64k/s) |
SOUND SELECTION | - Bit Mode: Select from 1 to 5 channels available with a signal input - Binary Mode: Select from 1 to 31 channels available with a signal input |
CONFORMITY STANDARDS | - CE Marking - RoHS - MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thompson Licensing |
PROTECTION RATING | - IP-54 (Upright Only) |
PLAYBACK OPTIONS | - Momentay Input: Message plays once - Sustained Input: Message repeats until input is open |
CONTROL OPTIONS | - Dry contact closure such as switches or relay contacts - Open-collector transistor (NPN only) |
OPTIONS | - Playlist Editor Program (for mp3 file arrangement)* - SDV-2GP:SDCard (for mp3 file transfer and storage)** *Available from Patlite with purchase of BKV unit **Other SD cards not guaranteed to work |
